Popolna evidenca servisov
Da
Serijska številka proizvoda
SD13Plus
Motor
Shangchai SC8D143G2B1
Izhodna moč motorja
94.2 kW (128 KM)
Transportne dimenzije (DxŠxV)
4500 x 3200 x 2500 mm
Informacije o stanju/garancija
ISO9001
Ohranjenost profila sprednjih pnevmatik
100
Opremljen za
propertynames.pp_equippedfor_2100012
Pogoji dostave
FOB, CFR, CIF, EXW
Drugi podatki
Technical Features
● Shangchai SC8D143G2B1 turbocharged diesel engine features strong power and high efficiency and energy conservancy.
● The high reliability power shift transmission and the two-stage final drive with spur gear reducing structure features reliable and stable power transmission, high durability, and high operating efficiency.
● The high-efficiency radiator can help the normal running of machine under high temperature environment and ease the daily maintenances.
● The integrally injection molded instrument panel adopts micro-computer control and reasonably arranged instruments, featuring more distinct displays.
● The optimized working lamp arrangement improves the lighting performance of vehicle.
● The reversing alarm and the working warning lamp are equipped to ensure higher construction safety.
● The instrument box and the gantry frame are isolated to relieve the transmission of vibration.
● The full box-type main frame features high carrying capacity against impact load and bending moment and the high quality welds guarantee the life cycle of the main frame.
● The external working valves ease the daily maintenances and realize better maintainability.
● The PPC pilot controls achieve better labor-saving and convenient operations.
● The working device system pressure is increased to 21MPa, featuring high efficiency and energy-saving.
● The rigid traveling system transmits the working load and impact load onto the main frame to guarantee the stability of machine under complicated working conditions.
● The new hexahedron cab features super-large interior space and broader visual field.
● The mounting surface and the sealing surface are separated to achieve better sealing performance.
● The floor fender adopts the labyrinth sealing structure, with the internal noise as low as 87dB.
Performance Parameters
Length × width × height (mm) (excluding ripper)4492×3185×2490Operating weight(t) (excluding ripper)13.7
Engine modelSC8D143G2B1Net power/rated speed (kW/rpm)95.5/1900
Ground pressure(Mpa)0.063Blade typeStraight tilting blade Angle blade
Blade capacity (m3)3.158 for straight tilting blade and 2.33 for angle blade
Applicable Working Conditions
Earthworks.Naprej
