Shantui SD32

Cena brez DDV

Vprašaj za ceno

Compnay LOGO
Images4
Shantui SD32 Buldožerji goseničarji
Shantui SD32 Buldožerji goseničarji
Shantui SD32 Buldožerji goseničarji
FavoritePriljubljena
shareDelež
Save searchShrani iskanje
Natisni

INFORMACIJE

Kategorija stroja / vozila
Buldožerji goseničarji
Znamka /model
Shantui SD32
Leto izdelave
2017
Dodatne možnosti
Novo/nerabljeno
Kraj stroja
Jining,Shandong
Država
Kitajska
Splošna ocena
1
2
3
4
5
Mascus ID
4F058AF2

PODROBNOSTI

Popolna evidenca servisov
Da
Bruto teža
37,200 kg
Tip kabine
Zaprta kabina
Emisijski razred
Stage II
Motor
NTAA855-C360S10
Izhodna moč motorja
232 kW (315 KM)
Menjalnik
SHANTUI
Transportne dimenzije (DxŠxV)
8560000 x 4130000 x 3640000 mm
Originalna barva
Yellow
Informacije o stanju/garancija
yes
Država izdelave
Kitajska
Pogoji dostave
FOB, CFR, CIF, EXW
Dodatna oprema
Ripper
Dodatna oprema
Klimatska naprava
Air conditioner
Dokumenti
SD32 bulldozer parameters.docx
Drugi podatki
ITEM 　UNIT SD32 L×W×H (Ripper not included) mm 6880×4130×3725 Operating weight (Ripper not included) t 37.2 Engine - CumminsNTA855-C360S10 Rated power kW/rpm 235/2000 Gradeability ° 30 Blade type - Straight tilt bladeSemi-U bladeAngle blade Blade width mm Straight tilt blade 4130×1590Semi-U blade 4030×1720Angle blade 5000×1140 Dozing capacity m3 Straight tilt blade 10Semi-U blade 11.9Angle blade 6 Ma× drop below ground of blade mm 560 Lift height of blade mm 1560 Ripper type - Single ripperThree-shank ripper Ripping depth of ripper mm Single ripper 1250Three-shank ripper 842 Lifting height of ripper mm Single ripper 955Three-shank ripper 883 Number of carriers (each side) - 2 Number of track rollers (each side) - 7 Number of track shoes (each side) - 41 Width of track shoe mm 560 Track gauge mm 2140 Ground length and ground pressure mm/MPa 3150-0.105 Pitch mm 228.6 Forward speed km/h 0–3.6 0–6.6 0–11.5 Reverse speed km/h 0–4.4 0–7.8 0–13.5Naprej
