Sunward SWE 100E

# SUNWARD SWE100E Crawler Excavator Specifications Model: SUNWARD SWE100E Operating Weight: 9500 kg Bucket Capacity: 0.40 m³ Transport Dimensions (L×W×H): 7120 × 2320 × 2680 mm Track Shoe Width: 450 mm Travel Speed (High/Low): 4.5 / 2.7 km/h Swing Speed: 10.8 rpm Bucket Digging Force: 64.5 kN Arm Digging Force: 43.0 kN Max Digging Depth: 4372 mm Max Digging Radius: 6950 mm Max Dumping Height: 5315 mm Ground Clearance: 360 mm Ground Pressure: 36.9 kPa ## Engine Engine Model: Kubota V3800-DI-T-E3B Rated Net Power: 60.7 kW / 2200 rpm Displacement: 3.769 L Cylinders: 4 Fuel Tank Capacity: 145 L ## Hydraulic System Main Pump Max Flow: 210 L/min Max Working Pressure: 28 MPa
