Doosan DH 60-7

# DOOSAN DH60-7 Crawler Excavator Specifications Model: DOOSAN DH60-7 Operating Weight: 5700 kg Bucket Capacity: 0.2 m³ Transport Dimensions (L×W×H): 5850 × 1880 × 2575 mm Track Shoe Width: 400 mm Travel Speed (High/Low): 4.2 / 2.4 km/h Swing Speed: 11 rpm Bucket Digging Force: 37.7 kN Arm Digging Force: 28.4 kN Max Digging Depth: 3820 mm Max Digging Radius: 6150 mm Max Dumping Height: 4030 mm Max Digging Height: 5760 mm Ground Clearance: 350 mm ## Engine Engine Model: Yanmar 4TNV94L Rated Net Power: 38.1 kW / 2200 rpm Displacement: 3.054 L Fuel Tank Capacity: 110 L ## Hydraulic System Main Pump Max Flow: 118 L/min Max Working Pressure: 20.6 MPa
