Kubota U 15

Company name:LONG WAY TRADING CO.,LTD Address:1898th Zaoxiang road ,Anyang City ,Henan province,China Contact: Nancy Tel : +8617739124690 WhatsApp:0086 13636464634 Wechat:17739124690 Email:

# Kubota U15 ## Main Specifications - **Engine**: Kubota D782-E2, 3-cylinder water-cooled diesel, displacement 778cc; rated power **9.6kW (13PS) @2300rpm**, mechanical direct injection, **no DPF** - **Operating Weight**: 1570kg (canopy standard); cab version approx. 1640kg - **Bucket Capacity**: 0.04 m³; bucket width 450mm - **Counterweight**: Integrated cast iron counterweight, zero tail swing. Rear body never overhangs track width. ## Transport Dimensions - Overall Length: 3480 mm - Overall Height: 2290 mm - Overall Width: **760 / 1010 mm (expandable tracks, minimum width 760mm)** - Ground Clearance: 145 mm - Track Ground Contact Length: 1540 mm ## Digging Performance - Max Digging Depth: 2310 mm - Max Digging Reach: 3900 mm - Max Digging Height: 3540 mm - Max Dumping Height: 2440 mm - Vertical Wall Digging Depth: 1910 mm - Boom Swing: Left 380mm / Right 500mm - Bucket Digging Force: 15.2 kN; Arm Digging Force: 7.8 kN ## Hydraulic System - Main Pump: Triple pump - **Auxiliary Hydraulic Flow (AUX): 26.7 L/min**, factory fitted breaker piping - Travel Speed: Low 2.2 km/h, High 4.3 km/h - Swing Speed: 8.7 rpm ## Tanks & Fuel Consumption - Fuel Tank: 18 L - Hydraulic Tank: 12 L - Fuel Consumption: approx. 1.5～2.1 L/h (lower for light landscaping work) ## Key Features - True zero tail swing, works tight against walls; ideal for basement & indoor demolition - Expandable tracks narrow down to 760mm, passes through very narrow doorways - Simple D782 engine, low failure rate, spare parts available worldwide, strong second-hand demand overseas - Standard auxiliary hydraulic circuit, ready for hydraulic breaker, auger, grapple
