Volvo EC 60 D

# VOLVO EC60D Crawler Excavator Specifications Model: VOLVO EC60D Operating Weight: 5580 kg Bucket Capacity: 0.23 m³ Transport Dimensions (L×W×H): 5885 × 1940 × 2560 mm Track Shoe Width: 400 mm Travel Speed (High/Low): 4.3 / 2.6 km/h Swing Speed: 9 rpm Bucket Digging Force: 42.3 kN Arm Digging Force: 28.5 kN Max Digging Depth: 3800 mm Max Digging Radius: 6100 mm Max Dumping Height: 4420 mm Max Digging Height: 5740 mm Ground Clearance: 380 mm Ground Pressure: 32 kPa ## Engine Engine Model: Volvo D2.6A Rated Gross Power: 36.5 kW / 2000 rpm Rated Net Power: 34.5 kW / 2000 rpm Displacement: 2600 cc Cylinders: 4 in-line, water-cooled diesel, turbocharged with intercooler Emission Standard: EU Stage IIIA Fuel Tank Capacity: 100 L ## Hydraulic System Hydraulic Type: Load sensing hydraulic system Main Pump Max Flow: 142.4 L/min Max Working Pressure: 26 MPa
