CAT 329 D
Cena brez DDV
Natisni
INFORMACIJE
Kategorija stroja / vozila
Bagri goseničarji
Znamka /model
CAT 329 D
Leto izdelave
2022
Delovne ure
1,564 h
Država
Kitajska
Splošna ocena
1
2
3
4
5
Mascus ID
9AD7F26C
CENA
Izberite valuto
PODROBNOSTI
Tip motorja
Dizel
Število prejšnjih lastnikov
1
Zadnji pregled
2025-08-14
Stanje podvozja
98%
Motor
original
Bruto teža
29,240 kg
Izhodna moč motorja
225 kW (306 KM)
Engine manufacturer
original
Emisijski razred
Stage V
Prostornina žlice
1.10 m3
Širina gosenic
600 mm
Transportne dimenzije (DxŠxV)
10410 x 2990 x 3180 mm
Originalna barva
original
Informacije o stanju/garancija
1 year
Pogoji dostave
FCA, FOB, CIF, EXW
Certifikati
EPA, CE
Dodatna oprema
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Nina
Whatsapp: +86 18055199047
Mobile:+86 18055199047
Wechat:18055199047
Email:
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs
Dodatna oprema
Klimatska naprava
Rešetkasta žlica
upravljalna ročica
Standardna izkopna žlica
Depth control
Drugi podatki
Model Number: 329D
Machine Type: Crawler Excavator
Power Source: Conventional Power
Bucket Type: Backhoe
Operating Weight Class: 29 tons
Operating Weight: 29240 kg
Overall Transport Length: 10410 mm
Overall Transport Width: 2990 mm
Overall Transport Height: 3180 mm
Engine Parameters
Engine Model: Cat® C7 ACERT™
Net Flywheel Power: 152 kW
Net Power - ISO 9249: 152 kW
Bore: 110 mm
Stroke: 127 mm
Displacement: 7.2 L
Hydraulic System Parameters
Maximum Flow (2x) - Main Implement System: 235 L/min
Maximum Pressure - Implement: 35000 kPa
Maximum Pressure - Travel: 35000 kPa
Maximum Pressure - Swing: 27500 kPa
Maximum Flow - Pilot System: 32.4 L/min
Maximum Pressure - Pilot System: 3900 kPa
Boom Cylinder - Bore: 140 mm
Boom Cylinder - Stroke: 1407 mm
Stick Cylinder - Bore: 150 mm
Stick Cylinder - Stroke: 1646 mm
CB1 Series Bucket Cylinder - Bore: 135 mm
CB1 Series Bucket Cylinder - Stroke: 1156 mm
Travel System Parameters
Travel Speed: 3.5/5.3 km/h
Maximum Drawbar Pull: 249 kN
Track Shoe Width: 600 mm
Track Gauge: 2390 mm
Number of Track Shoes per Side - Standard Undercarriage: 45
Number of Track Shoes per Side - Extended Undercarriage: 50
Working Range Parameters
Maximum Digging Radius at Ground Level: 10600 mm
Maximum Digging Depth: 7170 mm
Maximum Digging Height: 9990 mm
Maximum Dumping Height: 7020 mm
Maximum Vertical Digging Depth: 6510 mm
Fluid Capacity Parameters
Fuel Tank Capacity: 520 L
Cooling System Capacity: 30 L
Engine Oil Capacity: 30 L
Swing Drive Capacity: 10 L
Final Drive Capacity (per side): 6 L
Hydraulic System (including tank): 310 L
Hydraulic Tank Capacity: 145 L
Other Parameters
Swing Speed: 10.2 r/min
Counterweight Ground Clearance: 1110 mm
Rear Swing Radius: 3080 mm
Minimum Ground Clearance: 490 mm
