XCMG XCA 200
Cena brez DDV
Natisni
INFORMACIJE
Kategorija stroja / vozila
Rabljeni žerjavi za vsak teren
Znamka /model
XCMG XCA 200
Leto izdelave
2021
Delovne ure
3,000 h
Država
Kitajska
Splošna ocena
1
2
3
4
5
Mascus ID
6CEAC4AF
CENA
Izberite valuto
PODROBNOSTI
Inventarna št.
1
Zadnji pregled
2025-07-10
Serijska številka proizvoda
1
Število prejšnjih lastnikov
1
Bruto teža
150,000 kg
Dvižna nosilnost
200,000 ton
Registrska številka
1
Nosilnost na koncu kraka
200,000 ton
Najmanjša dolžina palice
14 m
Emisijski razred
Stage V
Dolžina teleskopa
16 m
Najmanjši pregibni krak
3 m
Premični krak
15 m
Dolžina kraka
15 m
Dvižna višina
84 m
Višina vodoravno postavljenega kraka žerjava
15 m
Višina dvignjenega kraka žerjava
14 m
Zgornji motor
Benz
Zgornje ure
857 h
Tip žerjava
Hidravlični drog
Originalna barva
Original
Protiutež
14000
Nosilec motorja
Original
Engine manufacturer
Original
Transportne dimenzije (DxŠxV)
15350 x 3000 x 3950 mm
Tip nosilca
Kolesni
Informacije o stanju/garancija
Good Condition
Znamka gum
米其林
Ohranjenost profila sprednjih pnevmatik
98
Ohranjenost profila zadnjih pnevmatik
2
Država izdelave
Kitajska
Pogoji dostave
FCA, FOB, CIF, EXW
Certifikati
EPA, CE
Dodatna oprema
Fly Jib,Hook,Counter Weight,ETC.
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Jason
Whatsapp: +86 13675656717
Mobile:+86 13675656717
Wechat:13675656717
Email:
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
Dodatna oprema
Kavlji
Drugi podatki
Basic parameters
The overall length of the machine is 15,350mm
Overall width of the machine: 3000mm
Overall height of the machine: 3950mm
Wheelbase: 2650/1650/2900/1650mm
Wheel base: 2590/2590/2590/2590/2590 mm
Axial load: 11650/11650/11650/10020/10020 kg
Maximum driving speed: ≥80km/h
Minimum stable driving speed: 1-1.5km/h
Minimum turning diameter: ≤18.5m
Minimum ground clearance: 307mm
Approach Angle: 18°
Departure Angle: 14°
Fuel consumption per 100 kilometers: 72 liters
Longitudinal span of outriggers: 9.19m
Maximum rotational speed: ≥1.5r/min
The turning radius at the tail of the turntable (at the counterweight point) : 5100mm
Full extension time of the boom: ≤720 seconds
Engine parameters
Chassis engine model: MC13.54-50/MC13.54-61
The rated power of the chassis engine is 338kW
The rated power of the engine on the vehicle is 221kW
Lifting capacity parameters
Maximum rated total lifting capacity: 200 tons
The maximum lifting moment of the basic boom is 6,657 kN·m
Longest main arm: 90 meters
Fixed auxiliary arm: 18.5m
The maximum length of the main boom and auxiliary boom is 118.5 meters
Job performance parameters
Working range: The maximum working range is 84 meters
Load-bearing extension and retraction: The main arm can extend and retract under load at any point within the working condition range. The comprehensive performance is no less than 40% of the rated load, and the maximum performance is 70% of the rated load. It has a wide construction range and the efficiency is increased by 30% to 50%
Variable support: Supports any combination of outrigger extension lengths, flexible operation, safe and stable
Full-action wireless remote control: Operated by a single person, it can achieve the disassembly and assembly of counterweights, foot pads, and auxiliary arms, reducing operational cost input
Other parameters
Hydraulic system: Utilizing advanced hydraulic technology, the system features high working pressure and large flow rate, ensuring that all movements of the crane are completed smoothly, quickly and accurately.
Electrical system: Equipped with an intelligent electrical control system, it features functions such as fault diagnosis and automatic protection, enhancing the reliability and safety of the crane.
Safety devices: A variety of safety devices are installed, such as overload protection devices, moment limiters, height limiters, amplitude limiters, anti-overturning devices, etc., to ensure the safety of the crane during operation
